Product Details:

Place of Origin: China
Brand Name: LIB INDUSTRY
Certification: CE,ROHS
Model Number: TH-100

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Packaging Details: Wooden Cases Standard Export Package
Delivery Time: 5-14 Days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram,Paypal
Supply Ability: 210 Sets/Quarter
Get Best Price Contact Now

Detail Information

Product Name: Psychrometric Test Chamber Temperature Range: -70 Degree ~ +150 Degree
Refrigerant: R404A, R23(environmental) Cooling Rate: 1 ℃ / Min
Heating Rate: 3 ℃ / Min Usage: Laboratories, Factories, University, Research Institutions
High Light:

98% RH Constant Humidity Chamber

,

Psychrometric Constant Humidity Chamber

,

98% RH psychometric test chamber

Product Description

98% RH Temperature Humidity Environmental Psychrometric Test Chamber



Description


Environmental psychrometric test chamber is used to experimentally study the behavior of systems and components under specific ambient conditions.



Humidity laboratory psychrometric chamber provides a constant high and low temperature environment condition ranges from -40°C to 150°C (Available for customized design). It is widely used to test the thermal performance of various products and components.



Main Parameter

Name

98% RH Temperature Humidity Environmental Psychrometric Test Chamber

Model

TH-100

TH-500

Internal Dimension (mm)

400*500*500

700*800*900

Overall Dimension (mm)

860*1050*1620

1180*1350*2010

Interior Volume

100L

225L

Heat load

1000W

Temperature Range

A : -20℃ ~ +150 ℃

B : -40℃ ~ +150 ℃

C: -70℃ ~ +150 ℃

Temperature Fluctuation

± 0.5 ℃

Temperature Deviation

± 2.0 ℃

Humidity Range

20% ~ 98% RH

Humidity Deviation

± 2.5% RH

Cooling Rate

1 ℃ / min

Heating Rate

3 ℃ / min

Cooling system

Mechanical compression refrigeration system

Refrigerating unit

French TECUMSEH compressor

Refrigerant

R404A, R23

Heating Element

Nichrome heater

Controller

Programmable color LCD touch screen controller



Ethernet connection, PC Link



Main Details

98% RH Constant Humidity Chamber Environmental Psychrometric Test Chamber 0

98% RH Constant Humidity Chamber Environmental Psychrometric Test Chamber 1

Automatic cycling water supply

1 50mm test hole in the left(customizable)





LIB INDUSTRY Test Chamber


Environmental Psychrometric Test Chamber used by air conditioner manufacturers are used to determine the thermal performance of unitary air conditioners and split systems. LIB INDUSTRY manufacture the test rooms as per customers’ requirement and standards as applicable.



98% RH Constant Humidity Chamber Environmental Psychrometric Test Chamber 2



Heating and Humidifying System


Environmental Psychrometric Test Chamber

1. Heater

Spiral nichrome tubular electric heating element heater , High accuracy temperature fluctuation and with long lifetime .



2. Humidifier

Use shallow slot method to humidify. Humidity measurment use wet and dry bulb method.



LIB Support Customization


Please tell us your test products and test requirements, and our team will provide you with a solution and one-stop service.
