800LTR IP54 Dust Test Chamber ISO20653 Standard

800LTR IP54 Dust Test Chamber ISO20653 Standard

Product Details:

Place of Origin: China
Brand Name: LIB
Certification: IEC60529,Rohs,CE
Model Number: DI-800,R56

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Packaging Details: Wooden cases standard export package
Delivery Time: 3-14days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram,paypal
Supply Ability: 360 sets / quarter
Get Best Price Contact Now

Detail Information

IP54 Test: IP5X Dust Test, IPX4 Water Test Application: Outdoor Products,Car
Standard: IEC60529,ISO20653 Model: 800L,1000L,Customization
After Sale: 3 Years Warranty Interior Material: SUS304 Stainless Steel
High Light:

IP54 Dust Test Chamber

,

800LTR Dust Test Chamber

,

ISO20653 dust testing equipment

Product Description

Description


The pollution of external factors is a great hazard to life and property. With IP54 grade(IP54 Test Chamber), the product can protect from proper amount of dust and water sprayed from all directions.



IP54 Rain and Dust Chamber

◆IP5X:Protection from the amount of dust that would interfere with the operation of the equipment.



◆IPX4:Protection from splashed water.



Technical Specification

800LTR IP54 Dust Test Chamber ISO20653 Standard 0

IP54 Rain Test Chamber

Model:R-800C

Standard IEC60529(IPX3 Test,IPX4 Test)
Workroom dimension (mm) 900*900*900 D*W*H
External dimension (mm) 1120*1460*1660 D*W*H
Swing Angle of Oscillating Tube
0 ~ ±180° (Adjustable)
Turntable Rotation Speed 1r/min (Adjustable)
Oscillating Tube Radius 400mm
Water Pressure Control Flow meter
Build-in Water Tank(mm) 370*375*950
Observation Window Double layer insulating glass with wiper





800LTR IP54 Dust Test Chamber ISO20653 Standard 1

IP54 Dust test chamber

Model:DI-800

Standard IEC60529(IP5x Test)
Internal Dimension (mm) 800*1000*1000
Overall Dimension (mm) 1040*1450*1960
Temperature Range Ambient ~ +50℃
Humidity Range < 30% RH
Normal Wire Diameter
50um
Nominal Width of a Gap Between wires 75um
Specimen Power Outlet Dust-proof socket 16A
Vacuum System Equipped with a pressure gauge, air filter, pressure regulator, connecting tube
Standard Configuration Sample shelf, dust wiper, talcum powder(5kgs)





Advantage


◆Controller:Programmable color LCD touch screen controller,Ethernet connection, PC Link, USB

◆Safety Device: Over-temperature Protection; Over-current Protection; Earth Leakage Protection;Phase Sequence Protection

◆Exterior Material:A3 Steel Plate with protective coating

◆Interior Material:SUS304 stainless steel

◆Maximum Noise:65 dBA

◆Standard:IEC 60529, ISO 20653



                          800LTR IP54 Dust Test Chamber ISO20653 Standard 2
