Electronic Temperature Humidity Chamber Temperature And Humidity Control In Laboratories
Product Details:
| Place of Origin: | China |
| Brand Name: | LIB |
| Certification: | CE RoHS ISO17025 CSA |
| Model Number: | TH-225 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Packaging Details: | Wooden cases standard export package |
| Delivery Time: | 10 days ( check if have stock) |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 360 sets / quarter |
|
Detail Information |
|||
| Name: | Environmental Test Chamber | Usage: | Auto Industry, Electronics |
|---|---|---|---|
| Humidity: | 10% To 98% RH | Standard: | IEC60068 |
| Warranty: | 3 Years | Payment: | T/T , L/C |
| High Light: | temperature and humidity test chamber,temp humidity chamber |
||
Product Description
Electronic Temperature Humidity Environmental Test Chamber,Cold Hot Humidity System
Application
◆Automobile Industry
◆Aircraft Industry
◆Electronics
◆Materials
◆Laboratory Calibration
◆University Research
Products Parameters
| Model | TH-225 |
| Internal dimension (mm) | 500*600*750 |
| Overall dimension (mm) | 960*1150*1860 |
| Volume | 225 L |
| Temperature range | -20℃ ～+150 ℃ |
| Low type | B: -40℃ C:-70℃ D: -86℃ |
| Humidity range | 20% ~ 98% RH |
| Temperature fluctuations | ± 0.5 ℃ |
| Temperature deviation | ± 2.0 ℃ |
| Humidity deviation | ± 2.5% RH |
| Heating rate | 3 ℃ / min |
| Cooling rate | 1 ℃ / min |
| Controller | Programmable color LCD touch screen controller, Ethernet , USB |
| Cooling system | Mechanical compression refrigeration system |
| Humidifier | Evaporating system |
| Air circulation | Centrifugal wind fan |
| Water supply system | Build in water tank & automatic water supply; |
| Exterior material | Steel Plate with protective coating |
| Interior material | SUS304 stainless steel |
| Environmental conditional | 5℃～+40 ℃ ≤85% RH |
 |
|
| Test Area | Cable Hole |
Key Features
- Temperature control and display unit
- Humidity control and display unit
- Programmable color LCD touch screen controller
- Mechanical compression refrigeration system
- Build-in water tank & automatic water supply
- USB and Ethernet
- Adjustable and removable sample shelves
- Safety protection system
- Temperature accuracy 0.1℃
- Different models
Advantages:
1. Different size chamber, from benchtops, reach-in to walk-in room
2. Various temperature range & humidity range
3. High stability of cooling system and humidity system
4. Data collection and download to USB
5. Popular and factory price
6. 3-Year warranty
7. Quick response within 24 hours
Packages
- Export Standard Wooden Box
- Can be used for Sea, Air, Railway, Truck transportation
- Package size: 3.3 m³, gross weight: 370kg
|
|
