Environmental Rubber Ozone Test Chamber Electronic Automatic Ozone Machine

Environmental Rubber Ozone Test Chamber Electronic Automatic Ozone Machine

Product Details:

Place of Origin: China
Brand Name: LIB
Certification: CE,ROHS,ISO17025
Model Number: OC-250

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Packaging Details: Wooden cases standard export package
Delivery Time: 3-10 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram,Paypal
Supply Ability: 180 Sets/ Quarter
Get Best Price Contact Now

Detail Information

Ozone Concentration: 1~1000PPHM Clamps Tensile Stretch: 5%~35%
Gas Sensor: Ozone Gas Sensor Ozone Generator: Silent Discharge Type Ozone Generator
Standard: ISO1431;ASTM 1149;IEC 60903 ;IEC60811-403;JIS K6259;ASTM D1171 Sample Holder: Static + Dynamic Combined Sample Holder
High Light:

ozone testing equipment

,

ozone aging test chamber

Product Description

Environmental Rubber Ozone Test Chamber Electronic Automatic Ozone Machine



Electronic Environmental Rubber Ozone Test Chamber Automatic Ozone Machine



►Specification of Electronic Environmental Rubber Ozone Test Chamber Automatic Ozone Machine

Ozone resistance test chambers test elastomers (rubber) in the condition of ozone exposure, to simulate and measure rubber aging by means of ozone within a few days.

Built with dynamic and static sample holders and others in accordance with the test method of ASTM D1149, IEX6006811-403, ISO1431, ASTM D1171. All models are upgraded to programmable controller and Ethernet access that provides simple operation and control.

►Advantages of  Electronic Environmental Rubber Ozone Test Chamber Automatic Ozone Machine

1. Floor Type

2. Automatic control and supply of ozone gas

3. USB and Ethernet download test data

4. Electromagnetic lock to prevent the door from opening under the working

5. CE mark

6. Standard and custom

7. Suit many types of environmental test conditions, Environmental Chamber offers flexibility, uniformity, and control accuracy

8. Available in a variety of sizes and configurations,36 Month Warranty, Lifelong Follow-up Services

►Main parameters of Electronic Environmental Rubber Ozone Test Chamber Automatic Ozone Machine

Name

Electronic Environmental  Ozone Test Chamber Automatic Ozone Machine

Model

OC-250

OC-500

OC-800

OC-010

Internal Dimension (mm)

600*600*600

700*800*900

800*1000*1000

1000*1000*1000

Overall Dimension (mm)

960*1150*1860

1180*1350*2010

1280*1550*2110

1500*1550*2110

Interior Volume (L)

250

500

800

1000

Temperature Range

0℃ ~ +100 ℃

Humidity Range

30% ~ 98% RH

Cooling Rate

Ambient ~ 0℃ within 20 min

Ozone Concentration

1~1000PPHM

Sample Holder Rotate Speed

0~10 r/min

Airflow Rate

0 ~ 60L/min

Clamps Tensile Stretch

5%~35%

Cooling system

Mechanical compression refrigeration system

Refrigerating unit

French TECUMSEH compressor

Refrigerant

R404A, R23

Heating Element

Nichrome heater

Controller

Programmable color LCD touch screen controller Ethernet connection, PC Link

Temperature Sensor

PTR Platinum Resistance PT100Ω/MV A-class, accuracy 0.001℃

Humidity Sensor

Dry and wet bulb sensor

Gas Sensor

Ozone gas sensor

Ozone Generator

Silent discharge type ozone generator

Air Circulation

Centrifugal wind fan

Door Lock

Electromagnetic lock

Sample Holder

Static + dynamic combined sample holder

Safety Device

Humidifier Dry-combustion Protection; Over-temperature Protection; Over-current Protection;

Refrigerant High-pressure Protection; Water Shortage Protection; Earth Leakage Protection

Thermal Insulation

Polyurethane foam and insulation cotton

Observation Window

Interior lighting, double-layer thermostability silicone rubber sealing

Power Supply

380V 50Hz

Standard

ISO1431;ASTM 1149;IEC 60903 ;IEC60811-403;JIS K6259;ASTM D1171

Maximum Noise

65 dBA

Environmental Conditional

5℃~+35 ℃ ≤85% RH

►Warranty and After services of Electronic Environmental Rubber Ozone Test Chamber Automatic Ozone Machine

1. 3 Years Warranty, Lifelong Follow-up Services. We have a professional after-sales team, if you have any questions during operation, we will supply solutions to you with 24 hours.

2. At first, our test chambers are produced based on 20 years product lifetime. Normally once test chambers have problems, we judge the problems, and send spare parts to our customers, and teach them how to change new parts by email or video. Within 3 years, all spare parts and shipping costs (by DHL, TNT, and FedEx) paid by our company LIB.

3. If customers need our engineers' on-site service, the company only needs to pay the ticket accommodation to our engineers, service is for free.

4. If Products still can't use after our engineers' repair, we will produce a new test chamber (same as the old one) to our customers with no charge.

5. You can contact our local service center in the overseas market to get service and products.

►Packaging  of Electronic Environmental Rubber Ozone Test Chamber Automatic Ozone Machine

1. First, a sealed chamber with a waterproof plastic film. Protect chamber from seawater corrosion.

2. Second, buffer foam is placed in the four corners of the chamber. It is used for fixing the equipment to prevent shaking and damaging chamber during transportation.

3. Plywood: standard wood export packaging. The wooden box is fixed by sheet metal to prevent damage during transportation.

Gross weight: 380kgs~

Package size: 2.5CBM

►Shipping of Electronic Environmental Rubber Ozone Test Chamber Automatic Ozone Machine

Material:Export standard wooden box

♦ Can be used for Sea, Air, Railway, Truck, and multimodal transport.

►Details of Electronic Environmental Rubber Ozone Test Chamber Automatic Ozone Machine

Environmental Rubber Ozone Test Chamber Electronic Automatic Ozone Machine 0

1. Controller

PID programmable color touch screen controller, network connection computer.

Can edit 120 programs 20 segments.

LIB also can preset the program into the controller based on user testing requirements.

The set system language is English for standard.

2. Ozone Exhaust Device

The ozone exhaust device is equipped with activated carbon to absorb ozone to make the workplace clean and safe.

Exhaust the gas after the test, automatically controlled on the controller

Environmental Rubber Ozone Test Chamber Electronic Automatic Ozone Machine 1

3. Rotating Sample Holder

Static + dynamic combined sample holder can stretch samples. A rotating sample holder allows the sample to be evenly exposed to the ozone condition.

4. Ozone Sensor

Ozone gas concentration detection transmitter.High accuracy, easy to exchange
