UVA UVB Glass 400nm UV Weathering Test Chamber

UVA UVB Glass 400nm UV Weathering Test Chamber

Product Details:

Place of Origin: China
Brand Name: LIB
Certification: CE,ROHS,ISO 17025

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Packaging Details: Wooden Cases Standard Export Package
Delivery Time: 5-14 Days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram,Paypal
Supply Ability: 410Sets
Get Best Price Contact Now

Detail Information

Bandwidth: 290~400mm Irradiance Control: 0.3~20 W/㎡
Distance Of Specimen And Lamp: 50mm Maximum Noise: 65 DBA
Irradiation Source: Fluorescent UV Lamps (6) - 40 W Name: UV Test Weathering Chamber
High Light:

400nm UV Weathering Test Chamber


UVB UV Weathering Test Chamber


400nm uv accelerated weathering tester

Product Description

UVA UVB Glass 400nm UV Weathering Test Chamber

► Description Of UV Test Weathering Chamber

400nm UVA UVB class UV test weathering chamber the capacity to perform accelerated weathering testing through the use of fluorescent UV chambers. This technique simulates the effects of sunlight in the short wavelength portion of the solar spectrum.
Evaluation criteria is based on visual properties (color change, gloss, haze, optical transmission) or structural properties (impact resistance, tensile strength, abrasion)

► Parameter Of UV Test Weathering Chamber

Name 400nm UVA UVB Glass UV Test Weathering Chamber
Model UV-SI-350

Internal Dimension (mm)


Overall Dimension (mm)


Specimen Holder Size(mm)



Programmable color LCD touch screen controller
Ethernet connection, PC Link,USB

Temperature Range

Ambient ~ 90 ℃ ±2℃

Black Panel Temperature (BPT)

35 ~ 80 ℃


290 ~ 400nm

Irradiance Control


Water Spray Cycle

1~9999H59M (Adjustable)

Power Supply

380V 50Hz

Maximum Noise

65 dBA

► Other Details UV Test Weathering Chamber

UVA UVB Glass 400nm UV Weathering Test Chamber 0

Sample Self
According to the requirements of the test glass, the sample holder is specially customized

PID programmable color touch screen controller, network connection computer. Can edit 100 programs 20 segment.


UVA UVB Glass 400nm UV Weathering Test Chamber 1

Irradiation: 0.55 W/m2;
The wavelength is 315 ~ 400 nm


Black Panel
Black panel temperature can be set at any point between ambiient to 90ºC depending upon the irradiance level,

Features of UV Test Weathering Chamber
1.Black aluminum plate is used to connect the temperature sensor, and the blackboard temperature meter is used to control the heating, and the temperature is more stable. The radiometer probe is fixed and does not require any loading and unloading.
2.The amount of radiation is measured by a high-precision display and measurement of a dedicated ultraviolet radiation meter.
3.Illumination and condensation can be independently controlled and alternate cycle control.
4.The independent control time for illumination and condensation and the time for alternate cycle control can be set arbitrarily within 1600hours.

UV Aging Test Chamber Standard
ISO 4892-1 Plastic-Methods of exposure to laboratory light sources
ASTM G-151 Standard Test Method for non metallic materials exposed to accelerated test equipment using laboratory light sources
ASTM G-154 Test Mothods for non-metallic materials exposed to the UV fluorescence device
British Standard BS 2781:Part5 Test Mothods 540B (Methods of exposure to laboratory light sources)
SAE J2020 Using fluorescent UV / condensation equipment for automotive exposure test
JIS D 0205 Burn-in test method of auto parts(Japan)

UVA UVB Glass 400nm UV Weathering Test Chamber 2
