IP 1000mm IPX3 IPX4 Ingress Protection Test Equipment

IP 1000mm IPX3 IPX4 Ingress Protection Test Equipment

Product Details:

Place of Origin: china
Brand Name: LIB
Certification: IEC60529,CE,RoHS,
Model Number: RNH-34

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Packaging Details: Wooden cases standard export package
Delivery Time: 18 days ( check if have stock)
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram,paypal
Supply Ability: 120 sets / quarter
Get Best Price Contact Now

Detail Information

Swing Angle Of Oscillating Tube: 0 To ±180° Adjustable Internal Dimensions (mm): According To Size Of IPX3X4 Oscillating Tube
Spraying Hole Diameter: φ0.4mm Hole Spacing: 50 Mm
Turntable Rotation Speed: 1r/min Adjustable Name: Ingress Protection Test Equipment
High Light:

IPX4 Ingress Protection Test Equipment

,

1000mm Ingress Protection Test Equipment

,

1000mm ip test equipment

Product Description

IP 1000mm IPX3 IPX4 Ingress Protection Test Equipment

■ Description of IPX3 IPX4 Test Equipment

IP 1000mm IPX3 IPX4 ingress protection test equipment is strictly designed according to IEC60529. It’s applied to the Electrical equipment of the waterproof test of IPX3 and IPX4.



The tubes oscillate to almost 180 ° either side of vertical. The degree of oscillation can be set on the touch screen controller or one of the three pre-set values, 90 ° , 120 ° , or almost 180 ° , can be selected.



■ Technical Specification of IPX3 IPX4 Test Equipment

Name IP 1000mm IPX3 IPX4 Ingress Protection Test Equipment
Model RNH-34
Internal Dimensions (mm) According to size of IPX3X4 oscillating tube
Overall Dimensions (mm) Uncertain
Oscillating Tube Radius 200mm, 400mm, 600mm, 800mm, 1000mm, 1200mm, 1400mm, 1600mm
Swing Angle of Oscillating Tube 0 to ±180° Adjustable
Spraying Hole Diameter φ0.4mm
Hole Spacing 50 mm
Turntable Rotation Speed 1r/min Adjustable
Controller Programmable color display touch screen controller, Ethernet, USB(Option)
Water Pressure Control Flow meter
Observation Window No Housing
Water Supply System Storage water tank, Booster pump, Automatic water supply, Water purification system
Interior Material SUS304 stainless steel
Power AC380V



■ More Details of IPX3 IPX4 Test Equipment



IP 1000mm IPX3 IPX4 Ingress Protection Test Equipment 0



Control Components

Programmable controller, easy to operate





Oscillating Tube
1200 (IPX3), 3600 (IPX4) or user-defined
4s for 2*1200, 12s for 2*3600 or user defined



IP 1000mm IPX3 IPX4 Ingress Protection Test Equipment 1
Turntable
Rotation speed of turntable 1~5r/min,adjustable
Bearing:50KG



Customize and Optional
200mm, 400mm, 600mm, 800mm,
1000mm, 1200mm, 1400mm, 1600mm





■ Features of IPX3 IPX4 Test Equipment

  ● For IPX3 and IPX4 testing
  ● The shell of the equipment and turntable are made by SUS304# stainless steel, to ensure rustless.
  ● Equip with adjustable trundles, makes the equipment easy to move.
  ● Oscillating tube drive:with features of low noise and high accuracy.
  ● Turntable drive:can adjust the speed and angle by touch screen, and auto control the directions (fit for the samples to do live test).
  ● Time setting for power: power off: 0-999min-power on: 0-999min-power off: 0-999min
  ● Control components:programmable touch screen



■ How to change the different oscillating tubes?
The connection parts of the oscillating tubes adopt flange structure, which is easy for disassembly and installation, and the support structure can be movable to achieve different distances, that makes the overall system can be compatible with different sizes oscillating tubes..



IP 1000mm IPX3 IPX4 Ingress Protection Test Equipment 2
