G154 Climate UV Weathering Test Chamber with Water Spray Cycle System
Product Details:
| Place of Origin: | China |
| Brand Name: | LIB |
| Certification: | CE,RoHS, |
| Model Number: | UV-SI-260 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Packaging Details: | Wooden Box standard export package |
| Delivery Time: | 3-12 days |
| Payment Terms: | T/T, D/P, D/A, L/C, Western Union, MoneyGram,paypal |
| Supply Ability: | 140 sets / quarter |
|
Detail Information |
|||
| Name: | UV Weathering Tester | UV Lamp: | UVA 340,UVB313 |
|---|---|---|---|
| Temperature Range: | Ambient~90℃ ±2℃ | Black Panel Temperature: | BPT 30~80℃ |
| UV Wavelength: | 290 ~ 400nm | Water Cycle: | Water Spray Cycle System |
| High Light: | Climate UV Weathering Test Chamber,G154 UV Weathering Test Chamber,G154 uv accelerated weathering tester |
||
Product Description
LIB G154 Climate UV Weathering Tester
Description
UV weathering tester can simulate the influence of the environment including sunshine, rain and dew by exposing the sample to the controlled inter-circulation of the sunshine and moisture with the high temperature.
Specification
| Name | UV Weathering Tester | |
|
Model |
UV-260 |
UV-SI-260 |
|
Internal dimensions (mm) |
450*1170*500 |
450*1170*500 |
|
Overall dimensions (mm) |
680*1300*1500 |
680*1300*1500 |
|
Capacity of test specimens |
48 pieces Individual specimen size is 75mm * 150mm |
48 pieces Individual specimen size is 75mm *150mm |
|
Controller |
Programmable color display touch screen controller |
Programmable color display touch screen controller |
|
Temperature range |
Ambient~90℃ ±2℃ |
Ambient~90℃ ±2℃ |
|
Humidity range |
≥95％R.H ±2%R.H |
≥95％R.H ±2%R.H |
|
Black Panel Temperature |
BPT 30~80℃ |
BPT 30~80℃ |
|
Irradiation Source |
Fluorescent UV lamps (8) - 40 W |
Fluorescent UV lamps (8) - 40 W |
|
UV wavelength |
290 ~ 400nm |
290 ~ 400nm |
|
Irradiance Control |
N/A |
0.3 ~ 20 W/㎡(340 nm / 313 nm) |
|
Water Spray |
Spraying water |
Spraying water |
|
Distance of Specimen and lamp |
50mm |
50mm |
|
Nominal power |
5000W |
5500W |
|
Power Supply |
380V 50HZ |
380V 50HZ |
Control System
 |
UV weatherometer 1.Adopts black aluminum plate to connect temperature sensor and adopts black board temperature meter to control heating so as to ensure more stable temperature. 2.The radiation quantity adopts the special UV irradiatometer with high-precision display and measurement. 3.The radiation intensity is not more than 50W/m2. |
Application Industry
uv weathering chamber
Paint ink paint, resin, plastic
Printing and packaging, aluminum, adhesives
Motorcycle industry, cosmetics,
Metal, electronics, electroplating, medicine and so on.
1.uv weathering tester simulate the sun, rain spray and condensation resulting damage to test the materials by exposure to sunlight with moisture and temperature.
2.To get the results of damage after several days or weeks which is equal to expose to outside for a few months. The damages include fading, discoloration, brightness down, powder, crack, blur, brittle, strength decreases and oxidation.
3.UV aging test chamber provide reference with testing data for improvement of existing materials, or to assess the impact of changes in product durability and other aspects
|
|
