UV Resistance UV Weathering Test Chamber 290nm ~ 400nm Wavelength
Product Details:
| Place of Origin: | China |
| Brand Name: | LIB |
| Certification: | CE,RoHS, |
| Model Number: | UV-SI-260 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Packaging Details: | Wooden Box standard export package |
| Delivery Time: | 3-12 days |
| Payment Terms: | T/T, D/P, D/A, L/C, Western Union, MoneyGram,paypal |
| Supply Ability: | 140 sets / quarter |
|
Detail Information |
|||
| UV Lamp: | UVA 340,UVB313 | Temperature Range: | Ambient~90℃ ±2℃ |
|---|---|---|---|
| Black Panel Temperature: | BPT 30~80℃ | UV Wavelength: | 290 ~ 400nm |
| Water Cycle: | Water Spray Cycle System | Humidity Range: | ≥95％R.H ±2%R.H |
| High Light: | 400nm UV Weathering Test Chamber,290nm UV Weathering Test Chamber,400nm UV Resistance Test Chamber |
||
Product Description
UV Resistance Test Chamber
Description
UV resistance test chamber simulates the environment of high temperature atmospheric pressure environment, UV lamp chamber is used to heat resistance test for electrical insulation, ventilation aging test of electronic parts, plasticizing product, leather textile test, treatment of mandatory ventilation, etc.
Specification
| Name | UV Resistance Test Chamber | |
|
Model |
UV-260 |
UV-SI-260 |
|
Internal dimensions (mm) |
450*1170*500 |
450*1170*500 |
|
Overall dimensions (mm) |
680*1300*1500 |
680*1300*1500 |
|
Capacity of test specimens |
48 pieces Individual specimen size is 75mm * 150mm |
48 pieces Individual specimen size is 75mm *150mm |
|
Controller |
Programmable color display touch screen controller |
Programmable color display touch screen controller |
|
Temperature range |
Ambient~90℃ ±2℃ |
Ambient~90℃ ±2℃ |
|
Humidity range |
≥95％R.H ±2%R.H |
≥95％R.H ±2%R.H |
|
Black Panel Temperature |
BPT 30~80℃ |
BPT 30~80℃ |
|
Irradiation Source |
Fluorescent UV lamps (8) - 40 W |
Fluorescent UV lamps (8) - 40 W |
|
UV wavelength |
290 ~ 400nm |
290 ~ 400nm |
|
Irradiance Control |
N/A |
0.3 ~ 20 W/㎡(340 nm / 313 nm) |
|
Water Spray |
Spraying water |
Spraying water |
|
Distance of Specimen and lamp |
50mm |
50mm |
|
Nominal power |
5000W |
5500W |
|
Power Supply |
380V 50HZ |
380V 50HZ |
Design Details
 |
|
| Sample Shelf | 8 UV Lamp |
|
|
| Programmable controller | Automatic water inlet |
Features
UV aging test chamber
★Colors touch screen display;interface Ethernet/USB
★Special air circulation system inside ensures testing accuracy.(Patented)
★Optional network video monitoring and data synchronization
★Environment-friendly refrigerating control technology, energy saving
★Automatic reminder of equipment maintenance plans and software of recording malfunction
★Optional APP mobility managemen
