280nm Light Test Xenon Arc Test Chamber For Colour Fastness
Product Details:
| Place of Origin: | China |
| Brand Name: | LIB |
| Certification: | CE,RoHS,ISO17025 |
| Model Number: | XL-750 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | USD7800 ~ USD19800 / SET |
| Packaging Details: | Wooden cases standard export package |
| Delivery Time: | 18 days ( check if have stock) |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram，paypal |
| Supply Ability: | 360 sets / quarter |
|
Detail Information |
|||
| Name: | Xenon Test Equipment For Colour Fastness | Certificate: | CE,RoHS,ISO17025 |
|---|---|---|---|
| Irradiance Range: | 100~1200 W/㎡ | Temperature Range: | Ambient ~100℃±2°C |
| BPT Temperature: | BPT +35 To +120 ℃ | Bandwidth Measurement: | 280nm~800nm |
| High Light: | Colour Fastness Xenon Arc Test Chamber,Light Color Fastness Tester,280nm Xenon Arc Test Chamber |
||
Product Description
Full Spectrum Xenon Test Chamber Xenon Exposure Water Spray Humidity Control
Description
Light Fastness And Colorfastness Tester Xenon Arc Test Chamber, The illumination simulation function of the full solar spectrum allows the sample to be exposed to the irradiation environment equivalent to summer noon sunlight for 24 hours, and obtain reliable accelerated aging data in a short period of time.
Products Parameters
|
Name |
Light Fastness And Colorfastness Tester Xenon Arc Test Chamber |
|
Model |
XL-750 |
|
Internal dimensions D*W*H |
950*950*850 mm |
|
Overall dimensions D*W*H |
1300*1420*1800 mm |
|
Specimen Capacity |
42pcs |
|
Specimen holder size |
95*200mm |
|
Irradiation Source |
1 piece of 6500 W water-cooled xenon lamp with inner quartz and outer borosilicate filter |
|
Irradiance Range |
100~1200 W/㎡ |
|
Bandwidth Measurement |
280nm~800nm |
|
Chamber Temperature Range |
Ambient ~100℃±2°C |
|
Black Panel Temperature |
BPT 35 ~85℃±2°C |
|
Relative Humidity Range |
50~98% R.H±5% RH |
|
Water Spray cycle |
1～9999H59M, adjustable |
|
Controller |
programmable color display touch screen controller, PC Link, R-232 interface |
|
Radiometer |
Tolerance: ±5% |
|
Heating system |
Nichrome heater |
|
Cooling system |
Mechanical compression refrigeration system |
|
Refrigerating unit |
French TECUMSEH compressor |
|
Humidification system |
External isolation, stainless steel surface evaporation humidifier |
|
Air circulation |
Centrifugal wind fan |
|
Water supply system |
Automatic water supply; Water purification system |
|
Safety device |
Humidifier dry-combustion protection; over-temperature protection; over-current protection; Refrigerant high-pressure protection; Water shortage protection, Earth leakage protection; |
|
Interior material |
SUS304 stainless steel |
|
Exterior material |
Steel Plate with protective coating |
|
Thermal insulation |
Polyurethane foam |
|
Observation window |
Interior lighting , double-layer thermo stability silicone rubber sealing |
|
Power Supply |
AC380V 50HZ |
Details
 |
|
|
| Sample holder | Compressor and water circulation system | Radiometer & Sensors |
Temperature Monitoring and Control
Colorfastness Tester
Temperature control is very important because it affects the aging rate. The temperature can be set at any point between -40°C and 100°C,
|
|
USE
The xenon lamp aging test chamber uses a xenon arc lamp that can simulate the full sunlight spectrum to reproduce the destructive light waves that exist in different environments
1. Corresponding environmental simulation and accelerated tests can be provided for scientific research, product development and quality control.
2. Variation tests that can be used to select new materials, improve existing materials, or evaluate durability after changes in material composition.
3. Light Fastness Tester can well simulate the changes of materials exposed to sunlight under different environmental conditions.
