DC30V Temperature Sensor For Tmeperature Climate Test Chamber
Product Details:
| Place of Origin: | China |
| Brand Name: | LIB |
| Certification: | RoHS,CE |
| Model Number: | PT-100 Sensor |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Packaging Details: | Wooden cases standard export package |
| Delivery Time: | 1-3 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram,paypal |
| Supply Ability: | 180 sets / quarter |
|
Detail Information |
|||
| Name: | Temperature Sensor | Working Voltage: | DC5V-DC30V |
|---|---|---|---|
| Working Current: | ≤15mA | Working Humidity: | 0-100% RH (non-condensing) |
| Output Signal: | ModBus-RTU 485 | Life: | 5 Years (in The Air) |
| High Light: | Climate Temp Humidity Sensor,Humidity Chamber Temperature Sensor,DC30V Temperature Sensor |
||
Product Description
Description
Pt100 means that its resistance is 100 ohms at 0 degrees, PT100 temperature sensor. It is a resistance temperature sensor made of platinum (Pt), which belongs to a positive resistivity. The relationship between its resistance and temperature change is as follows: R=Ro(1+α T)
Parameters
| Product name | Temperature Sensor for Tmeperature Climate Test Chamber |
| Working voltage | DC5V-DC30V |
| Working current | ≤15mA |
| Working temperature | -40 ~ 85 °C |
| Working humidity | 0-100% RH (non-condensing) |
| Output signal | ModBus-RTU 485 |
| Warm-up time | <10 seconds |
| Life | 5 years (in the air) |
| Line length | 60cm |
Precautions
 |
|
Scope of Application
●Temperature test chamber sensor
●Humidity test chamber sensor
●Temperature and humidity test chamber sensor
●Salt spray test chamber sensor
●Xenon lamp test chamber sensor
|
|
