ISO 9227 Climate Salt Spray Corrosion Chamber For Industrial Protective Coatings Testing
Product Details:
Place of Origin: | China |
Brand Name: | LIB INDUSTRY |
Certification: | CE,RoHS,ISO17025 |
Model Number: | S-250 |
Payment & Shipping Terms:
Minimum Order Quantity: | 1 Set |
---|---|
Packaging Details: | Wooden cases standard export package |
Delivery Time: | 5-14 days |
Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram,paypal |
Supply Ability: | 360 sets / quarter |
Detail Information |
|||
Product Name: | Salt Spray Corrosion Chamber | Internal Dimensions: | 640*1000*500 (mm) |
---|---|---|---|
Temperature: | Ambient ~60℃ | Usage: | Laboratory, University, Research Center |
Warranty: | 36 Months | Standard: | ASTM B-117; ISO9227 |
High Light: | Climate Salt Spray Corrosion Chamber,Industrial Salt Spray Corrosion Chamber,Protective Coatings Testing Salt Mist Chamber |
Product Description
ISO 9227 Climate Salt Spray Corrosion Chamber
Description
ISO 9227 Climate Salt Spray Corrosion Chamber,After the alternating salt spray test, the relative corrosion rate, structure, morphology and outdoor corrosion results of the samples are very similar.
This test can effectively evaluate many corrosion mechanisms, such as general corrosion, electrochemical corrosion and crevice corrosion, etc. Salt corrosion chamber is especially suitable for Corrosion testing of industrial protective coatings.
Name |
ISO 9227 Climate Salt Spray Corrosion Chamber |
Model | S-250 |
Internal dimensions | 640*1000*500(mm) |
Overall dimensions | 810*1800*1180(mm) |
Temperature range | Ambient ~60℃ |
Humidity range | 95% ~ 98% RH |
Temperature fluctuations | +/- 0.5 ℃ |
Temperature deviation: | +/- 2.0 ℃ |
Test time | 1~999 hours, settable |
Spray deposition | 1~2ml / 80cm2 · h |
Spray type | Continuous / Periodic |
Temperature Controller | LED display, P.I.D+S.S.R. microcomputer integrated controller |
Temperature sensor | PT100Ω / MV A-class |
Salt fog collected | Fog collector and fog measure cylinder |
salt water filtration | Salt water filter near the suction tubes( Avoid the nozzle blockage) |
Salt water preheating | Saturated air barrel |
Spraying system | Atomizer tower and Spray nozzles (Fog is more fine and uniform distribution) |
Interior /Exterior material | Glass fiber reinforced plastics |
Standard configuration | Sample bracket / sample holder / spray nozzle / Fog collectors / measure cylinder |
safety device | over-temperature protection, water shortage protection, over current protection, earth leakage protection |
Sealing | Hydrostatic hood seal |
Standard | ISO 3768/3769/3770, DIN50021-75, ASTM B-117, JIS H8502, IEC 68-2-11,IEC68-2-52, MIL-STD-750, ISO 9227 |
Power Supply | 220V 50HZ |
![]() |
|
Test Area | Observation Window |
Salt Test
This test can effectively evaluate many corrosion mechanisms, such as general corrosion, electrochemical corrosion and crevice corrosion, etc. Salt corrosion chamber is especially suitable for Corrosion testing of industrial protective coatings.
●Salt fog conditions: Salt fog conditions can be understood as ordinary neutral salt fog, which can spray 5% foggy sodium chloride solution through the nozzle.(Salt Spray chamber)
●Drying conditions: Drying conditions require sufficient air circulation in the test space, not only to control the drying temperature, but also to avoid the interference of additional corrosive gases and liquids.
●Humid conditions (constant temperature and humidity): Humid conditions need to provide specific temperature and humidity for the test space. The temperature range is generally between 35°C and 70°C, and the relative humidity range is generally between 95% and 100%.
●Spraying conditions: Spray the test solution (such as 5% sodium chloride solution) on the tested sample through the pressurized system and nozzle.(Salt corrosion test chamber)
●Standing conditions: Placed at room temperature, the sample usually undergoes a slow drying process without corrosive vapors and gases, almost no gas flow, and the temperature is usually 25±5'C. The relative humidity is 50% or lower.
![]() |
![]() |
