| Product Name: | Cryogenic Environmental Chamber | Temperature Range: | -120 Degree ~ +150 Degree |
|---|---|---|---|
| Heating Rate: | 3 ℃ / Min | Temperature Fluctuation: | ± 0.5 ℃ |
| Size: | Various Sizes To Choose | Usage: | Laboratories, Factories, University, Research Institutions |
| High Light: | Ultralow Temperature Cryogenic Environmental Chambe,-120C Cryogenic Environmental Chambe,-120C cryogenic test chamber |
||
Product Description
Description
Ultralow Temperature Cryogenic Environmental Chamber -120℃ ,After cryogenic treatment, the wear resistance, toughness and dimensional stability of metal tools can be significantly improved, and the service life of the workpiece can be doubled. Modification of workpieces such as shafts, rolls, valves, gears, springs, etc.
Cooling Method:Compressor refrigeration, environmentally friendly refrigerant.
Main Parameter
|
Name |
Ultralow Temperature Cryogenic Environmental Chamber |
||
|
Model |
CF-100 |
CF-225 |
|
|
Internal Dimension (mm) |
400*500*500 |
500*600*750 |
|
|
Overall Dimension (mm) |
860*1050*1620 |
960*1150*2010 |
|
|
Interior Volume |
100L |
225L |
|
|
Heat load |
1000W |
||
|
Temperature Range |
-120℃ ~ +150℃ |
||
|
Temperature Fluctuation |
± 0.5 ℃ |
||
|
Temperature Deviation |
± 2.0 ℃ |
||
|
Cooling Rate |
1 ℃ / min |
||
|
Heating Rate |
3 ℃ / min |
||
|
Cooling system |
Mechanical compression refrigeration system |
||
|
Refrigerating unit |
French TECUMSEH compressor |
||
|
Refrigerant |
R404A, R23 |
||
|
Heating Element |
Nichrome heater |
||
|
Controller |
Programmable color LCD touch screen controller,Ethernet connection, PC Link |
||
|
Interior Material |
SUS304 stainless steel |
||
| Power Supply |
380V 50Hz
|
||
Main Details
 |
|
|
| Test Hole | Environmental refrigerant | Controller |
Application Area
●Applied in industrial cold treatment, it is mainly reflected in the application of cold work die steel and high speed steel, bearing steel, cold work die and die accessories;
●The industrial cold treatment chamber can significantly improve the hardness and strength of the workpiece, ensure the dimensional accuracy of the workpiece, improve the wear resistance and impact toughness of the workpiece, and improve the internal stress distribution of the workpiece;
●Cryogenic test chamber mainly used in cold shrinkage of copper sleeves, bearings, etc., widely used in precision mechanical assembly;
●Cryogenic test equipment is also widely used in ultra-low temperature testing of large equipment (automobiles, large construction machinery, aircraft parts, aerospace equipment parts, military equipment parts);
