1C/Min R449a Temperature Constant Humidity Chamber

1C/Min R449a Temperature Constant Humidity Chamber

Product Details:

Place of Origin: China
Brand Name: LIB
Certification: CE,ROHS
Model Number: TH-500

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Packaging Details: Wooden Cases Standard Export Package
Delivery Time: 5-14 Days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram,Paypal
Supply Ability: 210 Sets/Quarter
Get Best Price Contact Now

Detail Information

Product Name: Humidity Artificial Climate Chamber Temperature Range: -70 Degree ~ +150 Degree
Humidity Range: 10%~98% Cooling Rate: 1 ℃ / Min
Heating Rate: 3 ℃ / Min Controller: Programmable Color LCD Touch Screen Controller
High Light:

R449a constant temperature humidity chamber


R449a Constant Humidity Chamber


1C/Min Constant Humidity Chamber

Product Description

Description of Temperature Humidity Climatic Teser

Temperature humidity climatic teser are the environmental test chambers designed specifically to replicate conditions of varying humidity in a controlled environment.


Constant temperature humidity climatic teser is undertaken for the purposes of evaluating products, materials, and components in response to differing conditions of water vapor and temperature in the environment.


Main Parameter

Name 1 ℃ / Min R449a Temperature Humidity Climatic Teser
Model TH-100 TH-500
Internal Dimension (mm) 400*500*500 700*800*900
Overall Dimension (mm) 860*1050*1620 1180*1350*2010
Interior Volume 100L 225L
Heat load 1000W
Temperature Range

A : -20℃ ~ +150 ℃

B : -40℃ ~ +150 ℃

C: -70℃ ~ +150 ℃

Temperature Fluctuation ± 0.5 ℃
Temperature Deviation ± 2.0 ℃
Humidity Range 20% ~ 98% RH
Humidity Deviation ± 2.5% RH
Cooling Rate 1 ℃ / min
Heating Rate 3 ℃ / min
Cooling system Mechanical compression refrigeration system
Refrigerating unit French TECUMSEH compressor
Refrigerant R404A, R23
Heating Element Nichrome heater
Controller Programmable color LCD touch screen controller

Ethernet connection, PC Link


Main Details of Temperature Humidity Climatic Teser

1C/Min R449a Temperature Constant Humidity Chamber 0


The internal material is 304 stainless steel, The test room is specially customized to meet the requirements of customers for testing metal detectors

Observation Window

The observation window with conductive film and lamp can clearly observe the changes of the sample


1C/Min R449a Temperature Constant Humidity Chamber 1

Refrigerating System

High temperature aging Chamber,Bipolar linkage refrigeration system, so that the temperature of the studio is more accurat

Cable Hole
cable port(portΦ50mm),Electrify the sample during the test


Industry Application

Damp heat climatic teser,Industries such as aerospace, military, automotive, medical and construction use humidity chambers in the testing of their products and materials due to the capability of moisture and temperature to drastically alter elements. Corrosion, warping, biological growth and cracking are all conditions that could result from the exposure of a product or material to extremes of humidity.


Therefore, it is imperative that manufacturers comprehensively test their products for the environmental conditions they will encounter during their lifespan in order to reveal these potential flaws or malfunctions.


Features of Temperature Humidity Climatic Teser

1.LCD display, can preset 999 program temperature & humidity control, repeated movement step by step

2.Human friendly control panel, easy observation and operation

3.PID controller guarantee accurate control, up to 100 control period, can set up to 99 hours 59mins

4.Mirror type stainless steel liner, semi-arc with four corner, detachable shelfs easy for cleaning

5.dry heat climatic teser equip 50mm view hole at left side

6.Built in Fluorescent light for easy observation

7.Large volume water tank, Water shortage power cutting function

8. Compressor and circulation fan and advanced air duct design


Our Services

1. If you face any problems in future during testing process we promise we will give you a reply within 48 hours and solution provide within 3 working days.


2.Excellent After sale Service: 36 months warranty. We would respond to the problem within 24 hours,and normally have a solution within 48-72 working hours if there is a problem occur.
